Wood Powder Grinding Machine:

Introduction of Wood Powder Grinding Machine:
This machine mainly crushing for soft mineral like that the hardness at about 3 level.
The mesh of grinding fineness in one time were at 10-325,
10-200mesh better using this machine,can control the material fineness at your own wishes.
The rate of acceptability could be 100%,no residue.
The whole machine is driven by one motor, with stable performance, fine finished products and lower cost.

SPEC of Wood Powder Grinding Machine:

1.advanced technology,stable performance
2.water-cooling double chamber
3.Low noisy,no Vibrate,durable and high output

Suitable material of Wood Powder Grinding Machine:

It is used to process bamboo wood flour, nutshell, Chinese herbal medicine, bark, leaf, wheat bran, mushroom, sesame, rice shell, corn cob, stalk, starch, shelled shrimps of grain type, spice, pepper, chili, fish flour, seaweed, dehydrated vegetable, flavoring substance, Chinese date, paper, circuit board, plastic, chemically raw material, mica, carbon, volcanic clay, perlite, distilled grain, furfural, cake type, charcoal, activated carbon, cellulose, potato slag, tea, hair, bean pulp, cotton, cow skin, sheepskin, plant root, stalk, leaf, flower, fruit, all kinds of edible fungus, etc and hundreds of difficult materials and is a ideal crusher in the industries of chemical engineering, building material, medicine, health care, breeding, food and mosquito-repellent incense, etc.

The Parameter of Wood Powder Grinding Machine:

Model NO.	TYMF 500	TYMF 800	TYMF 900
Main Power (kw)	18.5	30	55
Sieve machine power(kw)	1.1	3	5.5
Rotating speed (R/min)	3200	3200	2900
Number of cutter	36	72	96
Degree of fineness (mesh)	10-300	10-300	10-300
Feeding particle size(mm)	10	15	20
Output(t)	0.05-0.7	0.05-1	0.08-1.5
Installation Dimension  (m)	6*1.5*3.5	6*1.8*3.5	7*2.2*4

Noted: flammable and explosive materials prohibited to crush.

Professional Manufacture of Wood Powder Grinding Machine :

Zhengzhou Tianyuan Enviromental Protection Machinry CO.,LTD
Address: Longhai Railway Bridge, West Fourth Ring Road, Zhengzhou, Henan,China
Tel/Fax: 0086-371-67103029

If you are interested in our wood powder making machine,plz feel free to contact
us. We will do our utmost to serve you.
